M50
M50

M50

Multi-WAN Hotspot Router
  • Multi WAN Load Balance
  • Captive Portal/PPPoE Server
  • Smart bandwidth control
  • PPTP/L2TP/IPSec Server
  • Built-in AP Controller
IP-COM Multi-WAN Hotspot Router M50 is designed for small- and medium-sized enterprises to implement intelligent network access and management. It offers an AP management system and a multi-authentication management system, and supports various enterprise-oriented functions including filter management, intelligent bandwidth management, PPTP/L2TP/IPSec VPN, and multi-WAN.

Multi WAN Load Balance

M50 supports 4 WAN ports.  It can realize bandwidth averaging between two WAN ports base IP Group. Also it reserve the possibility of bandwidth expansion in the future.

Captive portal and PPPoE server

M50 integrates with captive protal service. A landing page will pop-up when mobile device connect to wifi network.  Once username and password is provided, the user will be able to access Internet.

Smart Bandwidth Control

M50 features with smart bandwidth management. It will adjust each user's download and upload bandwidth automatically according to all users bandwidth usage to avoid bandwidth insufficient.

PPTP/L2TP/IPSec Server

M50 supports multiple VPN protocols including IPsec, PPTP and L2TP in Client/Server mode.  It is easily to setup a secure data link between branch and headquater through LAN-to-LAN/Client-to-LAN mode.

Built-in AP Controller

M50 intergrates with AP controller to manage all IP-COM indoor access point. It will discover AP automatically when AP connect into network. You can edit AP's deployment location, SSID, Security, Output power, client limitation for SSID, Schedule Reboot etc function on the WEB UI at a single location.

  • Multi WAN Load Balance
  • Captive Portal/PPPoE Server
  • Smart bandwidth control
  • PPTP/L2TP/IPSec Server
  • Built-in AP Controller
IP-COM Multi-WAN Hotspot Router M50 is designed for small- and medium-sized enterprises to implement intelligent network access and management. It offers an AP management system and a multi-authentication management system, and supports various enterprise-oriented functions including filter management, intelligent bandwidth management, PPTP/L2TP/IPSec VPN, and multi-WAN.
Hardware Specifications
Dimension440*285*44(mm)

CPU800MHz Dual core

RAM512MB

FLASH128MB

Interfaces5*GE(1~4 WAN/ 4~1 LAN)
1*RJ45 Console


Power100-240V 0.7A 50/60Hz

Software Specifications
Max user capacity100

Max New sessions3900

Max Concurrent Sessions55000

MAX AP Manage number16APs

Internet Connection TypePPPoE/DHCP/Static IP

Authrization ServiceCaptive Portal, PPPoE

Captive Portal300 Portal Accounts
Customize E-bulletin


PPPoE Server100 PPPoE Accounts
Customize E-bulletin


Bandwidth ControlSmart Bandwith Control
Manual Definition


Internet Access ControlIP/mac/URL Filter

VPN ProtocalPPTP、L2TP、IPSEC

Port ForwardingPort Forwarding
DMZ


Security SettingIP-MAC Binding
ARP Attack Protection


DDNSDyndns/No-Ip

UPNPSupport

Firmware UpgradeLocal  firmware update
Online Firmware update


System ToolSchedule Reboot
Restore or Backup Configuration


Network Status ViewUser Statistics
Traffic Statistics
System Log
