AP255 v2
AP255 v2

AP255 v2

300Mbps Wireless In-wall Access Point
  • 2.4GHz 11n 300Mbps
  • Two 10/100Mbps LAN ports
  • Compliant with PoE 802.3af
  • Vlan tagging for multi SSID
  • 86 Type wall mount junction box design
  • Centralized managed by AC1000/AC2000/AC3000
AP255 is designed to provide wifi for hotel rooms,villa, large apartment etc premise. Adopt of 86 Type wall mount junction box design, it can blend into existing decoration perferctly without any damage. Compliant with PoE 802.3af standard enable it to be deployed quickly. It is easy to setup, manage and monitor with IP-COM AP controller.

11n Wireless 300Mbps

AP255 adopts of 11n wireless standard and wireless rates up to 300 Mbps on the 2.4GHz frequency band.  The devices such as smart phone, laptop connect to it can enjoy smoother video streaming and faster file transmission.

86 Type wall mount junction box design

AP255 adpots of 86 Type wall mount junction box design to blend into the existing decoration.It will pose no problem to neighbourhood panels or other decorations.

Compliant with PoE 802.3af

The port on the back panel support Power over Ethernet (PoE) functionality, which allows both power and data to be carried over a single Ethernet cable to AP255.

Advanced Wireless Security

AP255 offers multi mechanism to prevent unauthenticated acces and protect data privacy .
1.64/128bit WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
2.Wireless Access Control based on the mac address of wireless adapter
3.Client Isolation and SSID isolation

VLAN Tagging For multi SSID

AP255 can be configured to broadcast up to two SSID. Each SSID can be tagged to a specified networkVLAN for di erent user access based on established access rights.

Easy to setup, Easy to manage

AP255 can be managed by AP Controller, the administrator can setup, manage and monitor all the Aps online status more easily.

  • 2.4GHz 11n 300Mbps
  • Two 10/100Mbps LAN ports
  • Compliant with PoE 802.3af
  • Vlan tagging for multi SSID
  • 86 Type wall mount junction box design
  • Centralized managed by AC1000/AC2000/AC3000
AP255 is designed to provide wifi for hotel rooms,villa, large apartment etc premise. Adopt of 86 Type wall mount junction box design, it can blend into existing decoration perferctly without any damage. Compliant with PoE 802.3af standard enable it to be deployed quickly. It is easy to setup, manage and monitor with IP-COM AP controller.
Product Information
ModelAP255V2.0
DeploymentIn Wall
Weight (package included)140.1g
Dimensions86*86*35mm
Application ScenariosWiFi coverage for hotel rooms,villa
Hardware  Specification
Frequency2.4G
Compliant StandardIEEE 802.11b/g/n
Max Wireless Rate300Mbps
Interfaces2*10/100Mbps LAN
Button1*Reset Button
LED1*SYS LED
Max Power Consumption3.4W
Power SupplyPoE 802.3af
11b 1Mbps Tx Power18+/-1.5dBm
MCS 0 Tx Power18+/-1.5dBm
MCS 7 Tx Power17+/-1.5dBm
11B 1Mbps RX sensitivity-90dBm
11N MCS7 RX sensitivity-70dBm
Software  Specification
Operating ModesAP,Client+AP
WiFi On/offSupport
SSID HiddenSupport
Broadcast SSIDs2
Wireless Security64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Wireless Access ControlSupport(Based on mac address)
Output PowerAdustable step by 1dbm
AP IsolationSupport
User LimitationConnected user number limitation for each SSID
Weak Signal Client LimitationSupport
WMMSupport
VLAN Tagging for SSIDSupport
Captive PortalSupport(Work with AP Controller)
Remote AP MangementSupport(Work with AP Controller)
LED ON/offSupport
Diagosis Toolping
Schedule RebootSupport
Cicular RebootSupport
Device ManagementHttp Web
Log RecordSystem Log
Remote Log RecordSupport
Software UpdateLocal or AP Controller
Device RebootLocal or AP Controller
Device ResetLocal or AP Controller
Restore ConfigurationSupport
Backup ConfigurationSupport
AP ManagementAC1000,AC2000, AC3000
Others
Default Login IP192.168.0.254
Default Usernameadmin
Default Passwordadmin
Operating temperature-10℃~45℃
Storage Temperature-30℃ ~ 70℃
Operating Humidity10%-90% (non-condensing)
Storage Humidity10%-90%  (non-condensing)

AP255 is designed to provide wifi for hotel rooms,villa, large apartment etc premise. Adopt of 86 Type wall mount junction box design, it can blend into existing decoration perferctly without any damage.  Compliant with PoE 802.3af standard enable it to be deployed quickly.  It is easy to setup, manage and monitor with IP-COM AP controller.
