F1024 24-Port Fast Ethernet Rackmount Switch

F1024 provides 24 10/100Mbps autosensing ports and all ports support Auto MDI/MDIX for parallelwire and crosswire, making this device not only can be connection to common terminal equipments, but also can be cascade connection to other nerworking equipments to extend your networking easily.F1024 can provide you a easy, economic, high-performance solution for 100M networking, which is your ideal chioce for high-speed networking.
Highlights
● Compliant with IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX standard
● Support 8K MAC address list, MAC address learning and auto-ageing
● Built-in 2.5Mb SRAM (1.75Mb for packet buffer) to ensure the accuracy of data packet
● 6000V Lightning protection for power supply

F1024 provides 24 10/100Mbps autosensing ports and all ports support Auto MDI/MDIX for parallelwire and crosswire, making this device not only can be connection to common terminal equipments, but also can be cascade connection to other nerworking equipments to extend your networking easily.F1024 can provide you a easy, economic, high-performance solution for 100M networking, which is your ideal chioce for high-speed networking.


Features:


● Compliant with IEEE802.3, IEEE802.3u, IEEE802.3x

● Provide 24 10/100Mbps auto-negotiation ports

● Store & forward, share memory, non-blocking architecture

● Supports MAC address self-learning and auto MDI/MDIX

● Supports full-deplux 802.3x flow control and half-duplux backpressure flow control

● Support 8K MAC address list, MAC address learning and auto-ageing

● Built-in switching power adapter, support AC 110-240V 50/60Hz input

● 6000V Lightning protection for power supply

● Fanless design

● Standard 19-inch rack-mountable, 1U steel case

● Plug and play, no need configuration


Model No.F1024
Description24-Port Fast Ethernet Rackmount Switch
StardandIEEE 802.3、IEEE 802.3u、IEEE 802.3x
Transmission mediumUTP CAT3 or super for 10Base-T(<100m)
UTP CAT5 for 100Base-T(<100m)
CAT 5e(<100m)
Port and module24 FE RJ45 Ports
Backplane bandwidth4.8Gbps
Packet forwarding rate3.57Mpps
MAC address entries8K
Lightning protection6000V for power supply
Dimension440*178*44mm(L*W*H)
IndicatorsPower, Link/Act
Power supplyAC 100V-240V ~0.3A 50/60Hz
Power consumptionMAX 5.2W(220V/50Hz)
Operating temperature10% ~ 90% (noncondensing)
Storage temperature5% ~ 90% (noncondensing)
5% ~ 90% (noncondensing)0℃ ~ 45℃
Relative humidity(Storage)-40℃ ~ 70℃
